Lithium Coin Cells

Renata Batteries

Renata coin cell batteries are available with a capacity of 25mAh to 950mAh, 3V nominal voltage, guaranteed lifetime of 10 years, UL certified and they are designed for a temperature range of -40°C to +85°C. Renata coin cell batteries show a self-discharge rates of about 1% per year at a temperature of 23°C.

One version (CR2450HT) for the extended temperature range of -40 ° C to + 125 ° C, 490mAH capacity, is also available.

Product Features:

  • CR series
  • Nominal voltage of 3V
  • Capacity of 25mAh to 950mAh
  • Temperature range from -40°C to +85°C (125°C)
  • UL certified
  • Shelf life up to 10 years
  • Low self discharge of less than 1% per year at 23°C
renatanakedcoincells

Overview:

P/NDimensions (mm)Capacity (mAh)
CR1025 10.0 x 2.5 30
CR1216 MFR 12.5 x 1.6 30
CR1220 MFR 12.5 x 2.0 40
CR1225 12.5 x 2.5 48
CR1616 16.0 x 1.6 50
CR1620 16.0 x 2.0 68
CR1632 16.0 x 3.2 125
CR2016 MFR 20.0 x 1.6 90
CR2025 MFR 20.0 x 2.5 165
CR2032 MFR 20.0 x 3.2 225
CR2320 23.0 x 2.0 150
CR2325 23.0 x 2.5 190
CR2430 24.5 x 3.0 285
CR2450N 24.5 x 5.0 540
CR2450N-MFR 24.5 x 5.0 580
CR2477N 24.5 x 7.7 950


Tabbed coin cells

All Renata coin cells are also available with tab. The following options are possible:

Horizontal, 2 pins, SMD
Horizontal, 3 pins, THT
Vertical, 2 pins, THT
Vertical, 3 pins, THT
Isotan Tab, THT


Power Module

So called power modules (encapsulated batteries) protect the coin cell from external influence in harsh environmental conditions.

The following versions are available:

  • Vertical
  • Horizontal
  • Plug-in
  • Encapsulated Miniatures
