3PEAK – Operational Amplifiers with wide supply voltage range (HV OPA)

In addition to the zero-drift and low-noise operational amplifiers already presented in our newsletter, 3PEAK offers operational amplifiers with supply voltages up to 40V, referred to as HV operational amplifiers in the following. These also include amplifiers of the categories zero-drift and low-noise, as well as “general-purpose” amplifiers.


Thus, the 3PEAK portfolio includes operational amplifiers for various applications where higher supply voltages play an important role. E.G.


3PEAK High Voltage OPA

  • Industrial controls
  • Motor controls
  • Sensor interfaces
  • Instrumentation applications
  • And more



Highlights of the HV Operational Amplifier Portfolio

TPA1881/2

  • Supply Voltage: 4,5V…40V bzw. ±2,25V…±20V
  • Input Offset: ±15µV
  • Input Offset Drift: 0,05µV/°C
  • Input Noise: 0,1µVpp (@0,1Hz…10Hz)
  • Input Noise Density: 6nV/√Hz
  • EMIRR: 90dB @ 1GHz
  • Bandwidth: 12MHz

TPA1861/2/4

  • Supply Voltage: 4,5V…40V bzw. ±2,25V…±20V
  • Input Offset: ±30µV
  • Input Offset Drift: 0,01µV/°C
  • Input Noise: 0,1µVpp (@0,1Hz…10Hz)
  • Input Noise Density: 8nV/√Hz
  • EMIRR: 85dB @ 1GHz
  • Bandwith: 6MHz

Complete 3PEAK HV OPA Portfolio


Part Number Product Grade CH VDDmax(V) GBWP(MHz) Slew Rate(V/μs) eN@1kHz ( nV/√Hz ) VOS(max)(mV) VOS TC(µV/°C) Package
TPA2682 Industrial 2 36 20 10 10 3 2 SOP8,MSOP8
TPA2681 Industrial 1 36 20 10 10 3 2 SOT23-5
TPA2644 Industrial 4 36 1,5 0,5 50 2 2 SOP14,TSSOP14
TPA2642 Industrial 2 36 1,5 0,5 50 2 2 SOP8,MSOP8
TPA2641 Industrial 1 36 1,5 0,5 50 2 2 SOT23-5
TPA1882 Industrial, Automotive 2 40 12 10 6 0,02 0,05 SOP8,MSOP8
TPA1881 Industrial 1 40 12 10 6 0,02 0,05 SOT23-5,SOP8
TPA1864 Industrial 2 40 6 4 10 0,03 0,05 SOP14,TSSOP14
TPA1862 Industrial 2 40 6 4 10 0,03 0,05 SOP8,MSOP8
TPA1861 Industrial 1 40 6 4 10 0,03 0,05 SOT23-5,SOP8
TP27 Industrial 1 36 5 4 10 0,05 0,05 SOP8
TP2584 Industrial, Commercial 4 36 10 8 35 3 2 SOP14,TSSOP14
TP2582 Industrial, Commercial 2 36 10 8 35 3 2 SOP8,MSOP8
TP2581 Industrial 1 36 10 8 35 3 2 SOT23-5
TP2264 Industrial 4 36 3,5 13 28 2 2 SOP14,TSSOP14
TP2262 Industrial 2 36 3,5 13 28 2 2 SOP8,MSOP8
TP2261 Industrial 1 36 3,5 13 28 2 2 SOT23-5,SOP8
TP17 Industrial 1 36 7 20 25 0,1 1 SOP8
TP1284 Industrial 4 36 7 20 25 0,1 1 SOP14,TSSOP14
TP1282 Industrial 2 36 7 20 25 0,1 1 SOP8,MSOP8
TP1281 Industrial 1 36 7 20 25 0,1 1 SOT23-5,SOP8
TP1242 Industrial 2 36 1 0,7 45 0,25 1 SOP8,MSOP8
TP1241 Industrial 1 36 1 0,7 45 0,25 1 SOT23-5
TP07A Industrial 1 36 1 0,7 25 0,15 1 SOP8
LM358A Industrial, Commercial 2 36 0,9 0,5 70 3 7 SOP8,MSOP8,TSSOP8
LM324A Industrial, Commercial 4 36 0,9 0,5 70 3 7 SOP14,TSSOP14
LM321A Industrial 1 36 0,9 0,5 70 3 7 SOT23-5
LM2904A Industrial 2 36 0,9 0,5 70 3 7 SOP8,MSOP8
LM2902A Industrial 4 36 0,9 0,5 70 3 7 SOP14,TSSOP14

You need more information? Our team will be happy to advise you on the amplifier portfolio of 3PEAK or support you in the search for alternative components for your design
