Nuvoton – Non-Stackable Battery Monitoring ICs

Non-Stackable Battery Monitoring ICs of Nuvoton

In every battery-powered device, it must be ensured that the batteries are running within safe operating limits. For systems up to 110V, Nuvoton offers the perfect solution with its non-stackable battery monitoring ICs. Parameters such as voltage, temperature and current have to be permanently monitored. State of charge (SoC) and cell balancing also play an important role. Nuvoton offers components that combine all these functions in one single IC.



Products and Features

Nuvoton’s current offer includes four non-stackable battery monitoring ICs. Non-stackable means that they cannot be cascaded and hence only monitor a limited number of battery cells.




KA49503A

KA49511A

KA49517A

KA49522A

Operating Voltage [V]

12.5 – 85

12.5 – 45

12.5 – 85

12.5 -110

Operating Temperature [°C]

-40 – 105

-40 – 105

-40 – 105

-40 – 85

Max Series Cells

16

10

17

22

Cell Voltage Measurement Accuracy

±10

±10

±5

±5

Monitoring Function

U/I/T

U

U/I/T

U/I/T

High-Side FET Control

yes

yes

yes

yes

Cell balacnicng FET

int./ ext.

external

int./ ext.

int./ ext.

MCU Interface

SPI

SPI

SPI

SPI

Alarm Pin

2

1

1

1

GPIO

6

3

3

Package

LQFP80L

TQFP56L

TQFP64L

TQFP64L

Short-Datasheet


This ICs have several high resolution ADCs integrated to measure and monitor the various parameters. Products with current monitoring function also integrate a coulomb counter which is used to determine the State of Charge.

High-side FET control is used to switch charging and discharging by external FETs and thus also serve safe operation.

It is worth to mention that this product family also benefits from many years of experience with such systems in the automotive sector. Here, Nuvoton covers all current requirements for function and safety with non-stackable and stackable BMICs.

Applications

Nuvoton‘s BM-ICs are therefore suitable for several applications such as:

  • E-Bikes/ Pedelecs
  • UPS
  • Server Backup Systems
  • Power Tools
  • Energy Storage Systems

We are happy to support you in finding the right monitoring solution for your battery application.
